Kussmaul Auto Isolator 3 Controller

High Efficiency, No Diode Drop. Eliminates Diode Isolator in a 2 or 3 Battery System

• Volts to parallel, normal operation: 13.2 volts
  Hysteresis: 0.60 volts (13.2 volts on - 12.6 volts off)
  Battery Load: 0.020A
  Output Current: 3A
• System consists of a controller and two separate solenoids, for switching the batteries
• Allows a three battery system to be isolated from each other
• The system receives its power from the Battery one input or it can be switched ON/OFF
• When any of the three batteries go above 13.2V all three batteries are paralleled by the solenoids being energized, charging all three batteries and will disconnect the batteries when the voltage drops below 12.6V
